EASIEST OPERATION AND LOWEST MAINTENANCE COSTS
New and improved manual selector allows for hassle-free internal bleed without manipulating the position of the solenoid. Innovative labyrinth inlet eliminates the need for internal filters, reducing service costs for end users, contractors and Distributors.

FLOW CONTROL STANDARD ON ALL MODELS
Manual zone control from fully closed to maximum capacity at no extra charge.

APPLICATIONS
• Residential or commercial landscape irrigation applications
• For mild corrosive and mild acidity levels in the water
• For remote control, master valve and automated operations
• Reclaimed/reuse applications including municipally treated reclaimed water designated for irrigation

SPECIFICATIONS
• Recommended flow range:
¾” - 0.01 to 26 GPM
1” - 0.01 to 44 GPM

• Minimum operating pressure: 7 psi
• Maximum operating pressure: 150 psi
• Water temperature: up to 140˚ F
• 24VAC solenoid standard ± 10% voltage
• Solenoid inrush current: 0.220A
• Solenoid holding current: 0.095A

HIGH EFFICIENCY, LONGER LASTING SOLENOID
Inrush and holding current are 50-60% lower than the industry average which allows the industry’s longest wire runs from valve to controller. Low sensitivity to dirt and voltage fluctuations.

PROVEN RELIABILITY WITH RECLAIMED WATER
Over a decade of field-proven, consistent performance under the harshest water conditions. Durable and corrosion-resistant materials.

2-WIRE SYSTEM COMPATIBILITY
Works with all major manufacturer 2-Wire control systems.
